7300B Series

Angular contact ball bearings are able to support radial load and axial load. As single row Angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them as matched parts of bearings, preload for them is more convenient.
　　Retainers are made of brass, synthetic resins or others subject to individual bearing features and application conditions.

WGD Bearing No.	Boundary dimensions			Basic load ratings(kN)		Limiting speed		Mass
	mm			Dynamic	Static	rpm		kg
	d	D	B	Cr	Cor	Grease	Oil	≈
7301B	12	37	12	10.5	4.9	16,000	22,000	0.06
7302B	15	42	13	12.4	6.5	14,000	19,000	0.08
7303B	17	47	14	14.1	8.1	13,000	17,000	0.16
7304B	20	52	15	17.3	9.6	11,000	15,000	0.14
7305B	25	62	17	24.3	14.1	9,000	13,000	0.23
7306B	30	72	19	29.3	18.1	8,000	11,000	0.34
7307B	35	80	21	38.3	24.4	7,000	9,500	0.45
7308B	40	90	23	46.5	29.5	6,300	8,500	0.63
7309B	45	100	25	59.6	39.6	5,600	7,500	0.85
7310B	50	110	27	68.1	48	5,000	6,700	1.1
7311B	55	120	29	82.2	56.2	4,500	6,300	1.4
7312B	60	130	31	91.5	65.4	4,300	5,600	1.75
7313B	65	140	33	102.3	75.3	3,800	5,300	2.15
7314B	70	150	35	114.6	85.9	3,600	5,000	2.65
7315B	75	160	37	127.7	95.4	3,400	4,800	3.2
7316B	80	170	39	141.4	107.9	3,200	4,800	3.8
7317B	85	180	41	155.8	120.9	3,000	4,000	4.45
7318B	90	190	43	157.9	136.9	3,000	4,000	5.3
7319B	95	200	45	172	154.1	2,800	4,000	6.4
7320B	100	215	47	190	177.3	2,600	3,800	7.29
7321B	105	225	49	201.7	193.3	2,400	3,600	8.55
7322B	110	240	50	225.8	225.3	2,200	3,400	9.84
