7300AC Series

Angular contact ball bearings are able to support radial load and axial load. As single row Angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them as matched parts of bearings, preload for them is more convenient.
　　Retainers are made of brass, synthetic resins or others subject to individual bearing features and application conditions.

WGD Bearing No.	Boundary dimensions			Basic load ratings(kN)		Limiting speed		Mass
	mm			Dynamic	Static	rpm		kg
	d	D	B	Cr	Cor	Grease	Oil	≈
7300AC	10	35	11	9.5	4.4	18,000	26,000	0.053
7301AC	12	37	12	11.5	5.4	17,000	24,000	0.06
7302AC	15	42	13	12.5	6.2	15,000	21,000	0.084
7303AC	17	47	14	15	7.7	13,000	19,000	0.16
7304AC	20	52	15	17.9	9.6	12,000	17,000	0.15
7305AC	25	62	17	27	15.6	9,500	14,000	0.23
7306AC	30	72	19	32.8	20.4	8,500	12,000	0.35
7307AC	35	80	21	38.2	24.9	7,500	10,000	0.47
7308AC	40	90	23	47	31.1	6,700	9,000	0.66
7309AC	45	100	25	61.6	41.2	6,000	8,000	0.86
7310AC	50	110	27	71.9	48.5	5,600	7,500	1.08
7311AC	55	120	29	83.4	58	5,000	6,700	1.42
7312AC	60	130	31	95.2	67.2	4,800	6,300	1.71
7313AC	65	140	33	38	33.6	4,300	5,600	2.23
7314AC	70	150	35	118.8	88.2	4,000	5,300	2.67
7315AC	75	160	37	134.4	99.8	3,800	5,000	3.1
7316AC	80	170	39	149.5	107.7	3,600	4,800	3.6
7317AC	85	180	41	154.3	122.3	3,400	4,500	4.38
7318AC	90	190	43	177.6	153.5	3,200	4,300	5.6
7319AC	95	200	45	193.3	172.6	3,200	4,200	6.6
7320AC	100	215	47	213.5	198.6	3,000	4,000	7.58
7321AC	105	225	49	226.7	216.6	2,800	3,800	8.85
7322AC	110	240	50	253.2	252.4	2,600	3,600	10.5
