7200B Series

Angular contact ball bearings are able to support radial load and axial load. As single row Angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them as matched parts of bearings, preload for them is more convenient.
　　Retainers are made of brass, synthetic resins or others subject to individual bearing features and application conditions.

WGD Bearing No.	Boundary dimensions			Basic load ratings(kN)		Limiting speed		Mass
	mm			Dynamic	Static	rpm		kg
	d	D	B	Cr	Cor	Grease	Oil	≈
7200B	10	30	9	5.3	2.7	19,000	27,000	0.03
7201B	12	32	10	6.9	3.2	18,000	24,000	0.036
7202B	15	35	11	7.9	4.2	16,000	22,000	0.045
7203B	17	40	12	9.9	5.5	14,000	19,000	0.065
7204B	20	47	14	13.4	7.6	12,000	16,000	0.11
7205B	25	52	15	14.8	9.3	10,000	14,000	0.13
7206B	30	62	16	20.5	13.5	8,500	12,000	0.2
7207B	35	72	17	28.3	14.8	7,500	10,000	0.28
7208B	40	80	18	34.5	23.8	6,700	9,000	0.42
7209B	45	85	19	34	24.6	6,300	8,500	0.42
7210B	50	90	20	40.4	25.6	5,600	8,000	0.47
7211B	55	100	21	46.3	36	5,300	7,000	0.62
7212B	60	110	22	56.1	44.3	4,800	6,300	0.8
7213B	65	120	23	65.7	50.2	4,300	6,000	1
7214B	70	125	24	70.4	56.3	4,000	5,600	1.1
7215B	75	130	25	68.6	58.2	3,800	5,300	1.2
7216B	80	140	26	78.7	65.7	4,000	5,300	1.45
7217B	85	150	28	83.2	74.1	3,600	5,000	1.85
7218B	90	160	30	107.6	92.4	3,200	4,300	2.3
7219B	95	170	32	121.4	106.7	3,000	4,000	2.7
7220B	100	180	34	140.7	102.5	2,800	3,800	3.3
7221B	105	190	36	143.3	128.5	2,800	3,800	3.55
7222B	110	200	38	153.8	144.3	2,400	3,400	4.35
7224B	120	215	40	165.4	161.4	2,200	3,200	5.2
7226B	130	230	40	170.8	174.2	1,800	2,800	6.05

7200ACM/BM	URB	7206ACM/BM	ZKL	7212ACM/BM	NMB	7218ACM/BM	NAB	7226ACM/BM	TSC
7201ACM/BM	FLT	7207ACM/BM	ZVL	7213ACM/BM	TKO	7219ACM/BM	KHK	7228ACM/BM	FKL
7202ACM/BM	ZWZ	7208ACM/BM	SBP	7214ACM/BM	SPZ	7220ACM/BM	NTW	7230ACM/BM	IJK
7203ACM/BM	LYC	7209ACM/BM	BRB	7215ACM/BM	APZ	7221ACM/BM	CBN
